Solar Screen Mat Opal (Screen-OP)

• 1. Frosted polyester with satin surface
• 2. Bonding adhesive
• 3. High optical quality polyester
• 4. PS adhesive, glass polymerization within 15 days
• 5. Protection release liner, disposable after installation

TECHNICAL DATASHEET
Data calculated based on film applied to clear glass
3 mm thick (*on double glazing 4-16-4)
Ultraviolet transmission 5 %
Visible light transmission 60 %
Reflection of external visible light 27 %
Reflection of internal visible light 20 %
Total solar energy rejected 30 %
Total solar energy rejected 2* 30 %
Solar ratio :
 Solar energy reflection 21 %
 Solar energy absorption 18 %
 Solar energy transmission 61 %
Reduction in Solar Glare 27 %
g-value 0.71
u-value 5.6
Shading coefficient 0.8
Installation type : Interior
Roll length 30,5 m
Film composition PET
Thickness 60 μ
